Wellspring 100
Atmospheric Water Generator
The Origen Wellspring™ 100 Atmospheric Water Generator turns ambient air into 103 gallons of pristine, mineral-balanced drinking water per day—without drilling wells, trucking bottles, or worrying about drought.
- Water Production: 103 Gallons/Day*
- Efficiency: 3.5 Liters/kWh
- Supply Voltage: 230V
- Storage: 50 Gallon Storage tank
- Water Quality: 60-70 TDS
Features
Pure Water
4-stage filtration plus UV-C sterilization for clean, safe drinking water drinking water you can trust, exceeding WHO and EPA water quality standards.
Energy Efficiency
M-CORR™ thermal recycling generates water as low as 0.25 kWh per liter — up to 50% more efficient than legacy AWGs. Standard single-phase power means no special electrical infrastructure, helping to keep operating costs well below most bottled water contracts.
Ease of Use
No waving in front of a sensor. No waiting for it to work. No wasted water. Unlike IR sensors that misfire or miss entirely, the Wellspring dispenses at the push of a button, giving you precise, reliable control every time.
Safety & Performance
Certified to UL979 and UL60335-2-40 safety standards, and NSF 61, delivering clean drinking water you can trust. Coated steel exterior resists salt spray and corrosion in harsh climates.
Sustainability
Eliminate single-use plastic bottles and diesel delivery trucks from your water supply chain. Low GWP refrigerant and high-efficiency tech helps to reduce CO₂ emissions and minimize climate impact.
Water on Demand
Generate up to 144 gallons of drinking water per day from ambient air. No wells, no trucking, no municipal connection required. A 50-gallon onboard storage vessel and built-in booster pump deliver pressurized water to taps, ice machines, or irrigation lines.
How It Works
- Pull & Filter.
A fan draws air into the machine and through the first stage of filtration, capturing dirt, pollen, mold, smoke, bacteria, and more. - Extract & Condense.
- High-efficiency patented coil design pulls moisture as low as 15% relative humidity.
- Purify.
3-stage microfiltration helps to eliminate sediment, followed by germicidal UV-C sterilization for bacteria & viruses. - Balance & Polish.
High-quality Pentair remineralization cartridge restores a neutral pH for premium taste. - Store & Deliver.
50-gallon food-safe storage vessel and onboard booster pump push water up to bottles, taps, ice machines, or irrigation lines.
Built For the Long Haul
- Coated condensation module and marine-grade painted steel exterior helps resist corrosion from the elements.
- Electrical mechanical control system for simplicity and reliability.
- Future-proof design ready for solar, battery, or grey-water loop integrations.
Specifications
*Please note that all atmospheric water generator performance varies by external operating conditions (temperature and relative humidity). The performance conditions shown are based on 80°F, 60% RH conditions.
Performance
Output
103 gal / day
389 L / day
Efficiency
0.92 gal / kWh
3.5 L / kWh
Power
230 V, 60 Hz, single-phase
4650W
Size
48″ L × 41″ W × 62″ H
650 lbs
AIR Filter
MERV-13
18″ x 20″ x 2″
Current Draw
22.5 amps
Operating Range
56 °F Min –110 °F Max
BTU
68,026
Water
PH
7.5-8.5
Filtration Level
4-stage
Mineralization
Pentair 7cm
Tank Capacity
50 Gallons
The Origen Impact
- Slash operating costs versus bottled water.
- Demonstrate ESG leadership by removing diesel trucks and plastic waste from your supply chain.
- Earn resilience points with investors, regulators, and travelers who value water security.
- Install in a single afternoon and produce safe, great-tasting water that same day.
